PARAMETER
Material: Aluminum Alloy
Driver: 3V 3A for SST20, 219, LH351D
3V 6A for SST40, KW CSLPM1.TG, SFT40, 519A, LMP LML2AW.DC
6V 3A for XHP50.3 HI
6V 2.2A for B35AM, 719A
Lens type: Ar-coated glass lens
Reflector: orange peel for 219, LH351D, 519A, XHP50.3 HI, B35AM, 719A
smooth for SST20, SST40, KW CSLPM1.TG, LMP LML2AW.DC, SFT40
Low voltage warning: Yes
Reverse polarity protection: Yes
Temperature protection function: Yes, When the drive circuit reaches 55 degrees, the temperature protection will be triggered, and the current will slowly drop to reduce the heat output of the LED, but this does not mean that the surface of the flashlight will not be hot, and attention should still be paid when using it. If the surface temperature of the flashlight is too high, the user can also switch the brightness mode to medium brightness or low brightness.
Mode memory: Yes, If the flashlight is powered off for more than 3 seconds, the last mode will be remembered.
Tailstand: Yes
Battery included: No
Required battery type: unprotected 21700 lithium battery
Required battery quantity: 1 piece
Length / Diameter: 123mm / 26.6mm
Weight: 88g
4 modes: 0.1%-3%-30%-100%
12 groups:
1.click the switch to turn the flashlight on/off,tap the switch to select mode
2.if flashlight is turned on, tap the switch 20 times or more quickly to enter into config mode.(On a visual interface,as long as you click on an option, it means that the option is selected. The flashlight has no visual interface. It flashes to represent an option, and “tap the switch in the flashing process” means to select the option.)
Option 1 (normal-flash 1 time + buzz-flash): tap the switch to enter into sub-option to select the mode group,If the user has no operation, the config mode will enter option 2.
————-sub-option 1.1 (normal-flash 1 time) : tap the switch to select mode group 1 (0.1%, 1%, 10%, 35%, 100%, strobe, biking, battery-check)
————-sub-option 1.2 (normal-flash 2 times) : tap the switch to select mode group 2 (0.1%, 1%, 10%, 35%, 100%)
————-sub-option 1.3 (normal-flash 3 times) : tap the switch to select mode group 3 (100%, 35%, 10%, 1%, 0.1%)
————-sub-option 1.4 (normal-flash 4 times) : tap the switch to select mode group 4 (1%, 20%, 100%, strobe, biking, battery-check, SOS)
————-sub-option 1.5 (normal-flash 5 times) : tap the switch to select mode group 5 (1%, 20%, 100%)
————-sub-option 1.6 (normal-flash 6 times) : tap the switch to select mode group 6 (100%, 20%, 1%)
————-sub-option 1.7 (normal-flash 7 times) : tap the switch to select mode group 7 (0.1%, 1%, 10%, 50%, strobe, biking, battery-check, SOS)
————-sub-option 1.8 (normal-flash 8 times) : tap the switch to select mode group 8(0.1%, 1%, 10%, 50%)
————-sub-option 1.9 (normal-flash 9 times) : tap the switch to select mode group 9 (50%, 10%, 1%, 0.1%)
————-sub-option 1.10 (normal-flash 10 times) : tap the switch to select mode group 10 (1%, 10%, 35%, 100%)
————-sub-option 1.11 (normal-flash 11 times) : tap the switch to select mode group 11 (100%, 20%, strobe)
————-sub-option 1.12 (normal-flash 12 times) : tap the switch to select mode group 12(100% only)
Option 2 (normal-flash 2 times + buzz-flash): tap the switch to active the mode memory or inactive it,If the user has no operation,flashlight will enter into the last mode.
battery-check instructions:
<2.95V 1 flash,
2.95-3.25V 2 flashes,
3.25-3.55V 3 flashes,
3.55-3.85V 4 flashes,
>3.85V 5 flashes
